Vestwoods 5.12kWh Lithium Battery (Super LiFeP04)

USABLE POWER: (4.1kWh) 80% DOD 1C Rated Charge / Discharge

Vestwoods manufactures top quality intelligent lithium batteries which are internationally used for solar and backup systems. In Africa, the Vestwoods lithium range are installed in mobile telecoms solutions due to the reliability and life span of the products. Vestwoods originally developed the world's first intelligent BMS (Battery Management System) which was used in many other brands. The Vestwoods lithium battery range is designed with a 20 year life span and includes cooling to ensure efficiency and high performance at a very reasonable cost. What stands out on these batteries is the ability to supply high inrush currents, especially when starting up ac motors and heavy loads.

KEY FEATURES:

• High quality LFP cells
• Cycle Life 8000+ @ 80% DoD (Temp not higher than 35 degrees C)
• High rate charge/discharge current @100A
• 550A inrush current (10msec)
• Long design life up to 15+ years@ 25℃
• High Efficiency between charge and discharge
• Modbus/CAN/SNMP V2/SNMP V3 (optional)
• Multiple protection methods based on patented BMS
• Intelligent anti-theft solution

• Modular design for system scalability
• Compatible with various Hybrid inverters’ brands via communications port.
• • Deye
  • Sunsynk
  • Growatt
  • Lux Power
  • Victron
  • Voltronic Axpert | Kodak | Mecer etc
• Built in BMS that protects the cells from abnormal temperature, current, voltage, Short circuit, SoC and SoH.

SPECIFICATIONS:

Nominal Capacity - 100Ah@0.2C (25 degrees celsuis

Nominal Voltage - 51.2V DC

Rated Charge Voltage - 56.4V

Continuous Discharge Current - 100A@25 degrees C

Temperature Range of Charge - 0 to 60 degrees C

Recommended Temp Range - 15 to 35 degrees C (ideally 25 degrees C)

FINISHING:

Powder coated black

DIMENTIONS (mm):

Dimensions 442mm x 400mm x 130 (Rack design)
Weight 42kg

WARRANTY:

5 Years Manufacturing Warranty

10 Years Warranty Upgrade Option

Terms & Conditions apply.
