SUNSYNK 50kWHybrid Inverter

Store/Solar Energy Systems/Inverters

Product Details

Brand: 4SR Series Borehole Pump System

Sunsynk Solar Hybrid Inverters: 8.8kW Sunsynk Hybrid Inverter

Solar Batteries: Lithium-ion Solar Batteries

Weight: 75 kg

Sunsynk 3 Phase 50kW Solar Hybrid Inverter (3 Phase / Off-Grid / Hybrid / Parity)

Sunsynk 50kW is a 3Phase solar inverter, achieving a maxium output power of 50kW.

The 50kW Sunsynk Hybrid Inverter is a superior 3-phase inverter that can be used in off-grid and grid interactive applications. The Sunsynk 50kW hybrid inverter also includes a remote management platform to be able to monitor and configure PV plant parameters remotely using a web application.

The Sunsynk SUN-50K 3-phase High Voltage Battery Inverter is designed for commercial applications and residential systems such as guest houses and boutique hotels etc. Clients who want to take advantage of high efficiency solar solutions definitely should consider the Sunsynk solutions. We offer 2 x approved battery options to choose from; 60kWh Sunsynk High Voltage battery as well as a Greenrich High Voltage battery.

The 50kW Sunsynk Inverter supports unbalanced three-phase output. The Sunsynk 50kW Hybrid Inverter 3-Phase also has remote shutdown functionality and smart monitoring platform that allows for parameters to be set and firmware updates to be done remotely. The 50kW Sunsynk 3-phase hybrid inverter is a great choice as a solar energy system.

SUNSYNK HYBRID INVERTER SPECIFICATIONS:

100% unbalanced output, each phase; Max. output up to 50% rated power.
DC coupled and AC coupled to retrofit existing solar system.
Max. 10 pcs parallel for on-grid and off-grid operation; support multiple batteries parallel.
Max. charging/discharging current of 100A.
High voltage battery, higher efficiency.
6 time periods for battery charging/discharging.
Support storing energy from a diesel generator.

BATTERY DATA:

Battery Type: High Voltage Li-Ion.
Battery Voltage Range: 160VDC to 800VDC.
Max Charging Current: 50A + 50A.
Max Discharging Current: 50A + 50A.
Number of Battery Input: 2.
Charging Strategy for Li-Ion Battery: Self-adaption to BMS.

PV STRING INPUT DATA:

Min DC Input Power: 65 000W.
Min DC Input Voltage: 1000VDC.
Startup Voltage: 180VDC.
MPPT Voltage Range: 150VDC to 850VDC.
Full Load DC Voltage Range: 450VDC to 850VDC.
Rated DC Input Voltage: 600VDC.
PV Input Current: 36A + 36A + 36A + 36A.
Maximum PV (Isc): 55A + 55A + 55A + 55A.
No of MPP Trackers: 4.
Strings per MPP Trackers: 2.

AC OUTPUT DATA:

Rated AC Output and UPS Power: 50 000W.
Maximum AC Output Power: 55 000W.
AC Output Rated Current: 75.8A / 72.5A.
AC Current: 83.3A Maximum.
Continuous AC Passthrough: 150A Maximum.
Peak Power (Off Grid): 1.5 times of rated Power, 10S.
Generator Input: 75.8A.
Smart Load: 150A.
AC Couple Current: 75.8A.
Power Factor: 0.8 Leading to 0.8 Lagging.
Output Frequency and Voltage: 50/60Hz; 3L/N/PE 220/380VAC, 230/400VAC.
Grid Type: Three Phase.

Environment Limit:

Operating Temperature Range: -40°C to 60°C.
Cooling: Smart Cooling (Noise Factor <45 dB).
Communication with BMS: RS485 / CAN.
Protection: IP65.

SPECIFICATION SHEET:

Specifications sheet - Click Here

FINISHING:

Powder coated Cream / Siemens Grey

DIMENTIONS (mm):

Weight (kg): 75
Size (Length x Width x Height): 894 × 527 × 294 mm

WARRANTY:

5 Years Manufacurers Warranty - Terms & Conditions apply.
