Grundfos Solar Combo8 (150m 10 000L per day)

Store/Solar Pumps & Kits/Hybrid Solar Pumps - DC & AC Power/Grundfos Hybrid Solar Pump Combo's

Product Details

Brand: Grundfos

Weight: 125 kg

GRUNDFOS SQF COMBO8 SOLAR PUMP SYSTEM (150m | 10 000 Litres per day)

The High performance submersible DC/AC Grundfos solar pump combo is ideal for off-grid applications.

Fitted with a Grundfos 1,4kW MSF 3 Motor which offers flexible power range and can operated with either DC or AC power:

The MSF 3 motor has been developed with a view to high reliability which is achieved through the following features:

• carbon/ceramic bearings • excellent starting capabilities • various protection facilities

The protective circuit incorporated in the motor electronic unit cuts out the pump in case of dry running or similar situations like over temperature,

The wide voltage range enables the motor to operate at any voltage from 30-300 VDC or 90-240 VAC. This makes installation and sizing very easy.

The built-in electronic unit gives the SQFlex system a number of advantages compared to conventional products. One of these advantages is the built-in microprocessor with MPPT. Thanks to the MPPT function, the pump's duty point is continuously optimised according to the input power available. MPPT is only available for pumps connected to DC supply.

The flow levels on the Grundfos SQ Flex pump range is flexible dependent the well depth and panel configuration.

COMBO8 FLOW PROJECTION

Click here to download the full specifications & delivery details for this combo package

INCLUDED IN THIS COMBO

Grundfos SQF 1.2-3 Pump & Motor
Grundfos IO-50 DC Switch
5 x 270 Watt High Performance Renewsys Poly Crystalline A-Grade Solar Panels
1 x Sacrificial Anode (1kg)

FEATURES & BENEFITS

Dry-running protection
High efficiency
Overvoltage and undervoltage protection
Overload protection
Overtemperature protection
Maximum Power Point Tracking (MPPT)
Wide voltage range
Reliability

SPECIFICATIONS

Voltage -
- DC 30 - 300 Volt
- AC 90 - 240 Volt
Power - 1400 Watt
DC Motor - Brush-less / Oil cooled
Motor Outer Shell - 304 Stainless Steel
Pump Outer Shell - 304 Stainless Steel
Impeller style - Screw Type (Helical Rotor)
Impeller material - Stainless Steel / Rubber
Bearing - Carbon/Ceramic
Max Flow Rate - See flow diagram
Max Head - 250m
Outlet size - 1" (25mm)
Outlet -Stainless steel

SOLAR PV CONFIGURATION:

PV combination could range from 1 panel up to 14 depending the voltage and Amp ratings of the panels used. The Grundfos SQ Flex range have been well tested and trailed with the Renewsys A Grade (Poly)Multi Crystalline Panels.

Please make use of our well experienced team to assist with your design and suggested panel configurations for your project.

For assistance please complete the pump sizing information to assist with your specifications.

Click here - PUMP SIZING INFORMATION FORM

WARRANTY

1 Year manufacturing warranty (Terms & Conditions Apply)
