PRESSURE BOOSTER COMBO 5 - Large Home & Garden Irrigation

Low-maintenance and easy operation

Making use of a LEO EVP vertical multi-stage pump and VSD (Variable Speed Drive) controller to ensure adequate water flow at specific pressure levels. The EVP pump combo is fully adjustable from low to medium speeds and capable of pressure ranges from 2 to 5 bar pressure at a flow of up to 150 l/min and is ideal for large homes and garden irrigation applications.

PUMP:

• Type - Vertical Multi-Stage
• Cast Iron water inlet and outlet - anti-rust treated
• Support - anti-rust treated
• Impeller - Special Plastic Material
• AISI 304 stainless steel shaft
• Max. suction - 8m

MOTOR:

• Make - LEO
• Model - EVPm6H-4
• Power rating - 1.5kW (1500 Watt) 220 Volt
• Phase - Single
• C&U bearing
• Motor with copper winding
• Built-in thermal protector (Single Phase)
• Insulation class - F
• Protection class IPX4
• Max. ambient temp - 40 *C

VSD CONTROLLER:

• Serio - (Electronic)
• Variable Speed Control
• Max Pressure Point - 8 bar
• Max Pressure Limit - 10 bar
• Dry running protection
• Over current protection
• Connection thread - G1"1/4 (32mm)
• Protection class - IP65
• Rated motor power: 0.37 - 1.8kW

SPECIFICATION SHEET:

Download a printable flow diagram and specifications sheet - Click Here

WARRANTY:

LEO pump and controller come with a 2 year manufacturing warranty. (Terms & Conditions Apply)

OPTIONAL: (Can be selected on checkout)

WATER FILTRATION: (TRI-UC-02)

BENEFITS:

Limited space required

Simple to maintain

Removes contaminants

Eliminates odours

FEATURES:

Recommended flow 1.9-3.8L/min

Sediment pre-filter included

Laboratory tested

Rain Water & Rain Water Harvesting

Municipal water

NOT SUITABLE FOR:

WARRANTY:

All Tripple UC-02 Combo Water Filtration Systems come with a 2 year manufacturing warranty. (Not applicable on filters or due to poor installation) (Terms & Conditions Apply)
